TP-6714 4/10 Appendix 129
Set System
D Source Type: Utility/Generator, Generator/Generator,
Utility/Utility, Utility/Generator/Generator (3--source system)
D Transition Type: Standard/Programmed/Closed
d Prog Transition Override Automatic/Manual
(closed-transition only)
D Service Entrance No/ICCB/MCCB
D Rated Current, Amps
D 3 Source Engine Start Mode
d Mode1/Mode2
d Preferred Source Toggle Enable/Disable
D Transfer Commit Commit/No Commit
D Remote Test Loading Loaded/Unloaded
D Peak Shave TD Bypass Enable/Disable
D USB Data Logger Collection Period
seconds/minutes/hours/days
d Min/Max Values Calendar/Continuous/Days/Weeks
d Start Date and Time
d Days/Weeks
d Start/stop
Set Communications
D Modbus Server TCP Enable/Disable
D Modbus Server Port 1 or 2
Enable/Disable
D Modbus Address Port 1 or 2
D Baud Rate Port 1 or 2
9600/19200/57600
D Modbus TCP Unit ID
D IP Address
D Subnet Mask
Set Passwords
D Setup Password
D Test Password
Calibration
D Line-Neutral Voltages, Source N and E
D Line-Line Voltages, Source N and E
D Load Current, LA, LB, and LC
Reset Data
D Reset Maintenance Records, Yes or No
D Reset Event History, Yes or No
D Reset Default Parameters, Yes or No
D Reset Exercise Setup, Yes or No
D Reset Test Password, Yes or No
D Disable Test Password, Yes or No
D File Maintenance
d Delete Files
d Force History Save
USB Access Screen (appears only when a device is
connected to the USB port)
D Download to Controller
D Upload to USB
d File/Data Log
d Filename and Free Space, kB
d USB Data Logger Start/Stop
To Next Page
