Kohler MPAC 1500

TP-6714 4/10 77Section 5 Setup
Set Sources, continued
Set Normal Source
Emergency
BY"Back
Normal Source
Set Number of Phases
BY"Back
Save Back
? Phase
Normal Source
Set Voltage
BY"Back
Back Save
Set Voltage
?
?? VAC
Normal Source
Set Frequency
BY"Back
Back Save
Set Frequency
??
Hz
Normal Source
Set Under Voltage
Pickup
BY"Back
Pickup
??? % of Nominal
85--100%
Save Back
Normal Source
Set Under Voltage
Dropout
BY"Back
Dropout
??? % of Pickup
75--98%
Save Back
Normal Source
Set Over Voltage
Pickup
BY"Back
Pickup
??? % of Dropout
95--100%
Save Back
Normal Source
Set Voltage Debounce
BY"Back
Debounce Time
?.? Seconds
0.1 -- 9.9 Seconds
Save Back
Normal Source
Voltage Unbalance
Enable/Disable
BY"Back
Save Back
Voltage Unbalance
Enable/Disable
Normal Source
Voltage Unbalance
Pickup
BY"Back
Pickup
??%
3--18%
Save Back
Normal Source
Set Over Voltage
Dropout
BY"Back
Dropout
??? % of Nominal
106--135%
Save Back
Source Setup Screens Continued from Previous Page:
Note: The same menus are available
for the Emergency source.
