5.2 Various problems and countermeasures
108
Status Error description Corrective actions
No image is acquired.
*2
No image appears after X-ray exposure.
(1) Check the following items.
• Did you perform exposure in "Ready" status?
• Are the exposure conditions correct?
• Was X-ray output lowered?
• Was X-ray voltage set to a lower value?
(2) Perform the following procedures.
• For AeroDR 1417HQ, AeroDR 1417S,
AeroDR 1717HQ and AeroDR 1012HQ
– Set the sensitivity setting of the image
processing controller to "Large" before
exposure. If the setting is already set to
"Large", increase the voltage of the X-ray
and perform exposure.
• For AeroDR 2 1417HQ, AeroDR 2 1417S,
AeroDR 3 1417HD, AeroDR 3 1717HD and
AeroDR 3 1012HQ
– Increase the voltage of the X-ray before
exposure.
Reading has automatically
started.
*2
The machine starts reading the image without
X-ray exposure.
(1) Check the following items.
• For AeroDR 1417HQ, AeroDR 1417S,
AeroDR 1717HQ and AeroDR 1012HQ
– Was the DR Detector subjected to strong
shocks or vibrations while "Ready" was
displayed?
– Is the sensitivity setting of the image
processing controller correct? (Is the
sensitivity setting of the image processing
controller set to "Large"?)
• For AeroDR 2 1417HQ, AeroDR 2 1417S,
AeroDR 3 1417HD, AeroDR 3 1717HD and
AeroDR 3 1012HQ
– Was the DR Detector subjected to strong
shocks or vibrations while "Ready" was
displayed or wasn't an X-ray exposed
nearby?
(2) Use caution to prevent strong shocks or
vibrations and restart exposure.
Exposure was performed in a
condition other than when the ex-
posure with the image processing
controller was possible.
*2
Exposure was performed when "Ready" was not
displayed on the image processing controller.
Consequently, a correct image was not acquired.
Wait for one minute or more before starting
the next exposure.
Exposure was performed when "Ready" was
not displayed.
Wait for 30 seconds or more before starting
the next exposure.
*
1 The AeroDR 1012 HQ and AeroDR 3 1012 HQ cannot be inserted into the AeroDR Battery Charger.
* 2 Troubleshooting in the Aero Sync mode.
IMPORTANT
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
• If the exterior or protective cover is damaged extensively, contact Konica Minolta technical representatives.
•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••
