Internal Graphics Configuration:
BIOS SETUP UTILITY
Chipset
Internal Graphics Configuration
Internal Graphics Mode [UMA]
UMA Frame Buffer Size [Auto]
Current UMA Size [128MB]
Primary Video Controller [PCIE/IGFX/PCI]
Video Display Devices [Auto]
TV Standard [NTSC]
Expansion Mode [Disabled]
Disabled
UMA
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
Internal Graphics Mode Disabled
UMA
Disabled
UMA
UMA Frame Buffer Size
Auto
32MB
64MB
128MB
256MB
512MB
1024MB
auto
32MB
64MB
128MB
256MB
512MB
1024MB
Primary Video Controller
PCIE/IGFX/PCI
PCI/PCIE/IGFX
IGFX/PCIE/PCI
PCIE/IGFX/PCI
PCI/PCIE/IGFX
IGFX/PCIE/PCI
Video Display Devices
Auto
CRT Only
LCD Only
DFP Only
TV Only
CRT Force(Auto)
TV Force(Auto)
CRT/TV Force
Auto
CRT Only
LCD Only
DFP Only
TV Only
CRT Force(Auto)
TV Force(Auto)
CRT/TV Force
TV Standard
NTSC
PAL
PAL-M
PAL-60
NTSC-JAP
PAL-CN
Pal-N
Scart_RGB
NTSC
PAL
PAL-M
PAL-60
NTSC-JAP
PAL-CN
Pal-N
Scart_RGB
Expansion Mode Enabled
Disabled
Enabled/Disabled Expansion Mode
