KT690 Family
KTD-00738-C Public User Manual Date: 2008-09-16 Page 86 of 91
Displays Configuration:
BIOS SETUP UTILITY
Chipset
Displays Configuration
LVDS [None]
Backlight Signal Inversion [Disabled]
LCDVCC Voltage [3.3V]
TMDS Support [Auto]
Display module V0.04
<- Select Screen
|| Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
V02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Feature Options Description
LVDS
None
Select Panel setup
Backlight Signal Inversion
Disabled
Enabled
Select signal Polarity
LCDVCC Voltage
3.3V
5.0V
LVDVCC voltage selection (power sequenced)
TMDS Support Disabled
Enabled
Auto
Disabled
Enabled
Auto
