16 Spare parts
16.3 Repair kits
16.3.2 Repair kit overflow valve KF/KH/KV851–1301
Notice The repair kit contains only the numbered parts and is only supplied complete.
164
729.4
914.2
501
064
305
629
306
914.5
165.1
914.6*
Qty. Item No. Part Qty. Item No. Part
1 064 Supporting ring 1 629 Valve housing
1 164 Adjusting screw 1 729.4 Flat gasket
1 165.1 Screw plug 7 914.2 Socket screw
1 305 Valve body 1 914.5 Socket screw
1 306 Groove nut 4 914.6* Socket screw
1 501 Pressure spring
* Only for Type KV: replaces 4 pieces 914.2
Tab.26: Repair kit overflow valve KF/KH/KV851–1301
Operating instructions
OIK 09en-GB Edition 2019-11
51
