3 Identification
3.1 Type code
3 Identification
3.1 Type code
KF - 1301.DBA.000372
1
2
3
4
5
6
Fig.1: Type code
Item Classification Description
1 Type KF
o Pump with free shaft end
o Pump with inline flanges PN16
o Pump unit with or without pump bracket foot
KFA
o Pump with free shaft end
o Pump with overhead flanges in special design PN16
o Pump unit with or without pump bracket foot
KFN
o Pump with free shaft end
o Pump with overhead flanges PN6
o Pump unit with or without pump bracket foot
KFT
o Pump with free shaft end
o Pump with overhead flanges PN16
o Pump unit with or without pump bracket foot
KH
o Pump with foot for horizontal mounting
o Pump with inline flanges PN16
o Pump unit on base frame
KV
o Pump with pedestal for vertical mounting
o Pump with inline flanges PN16 for vertical mounting
o Pump unit on pedestal for vertical mounting
KVT
o Pump with pedestal for vertical mounting
o Pump with overhead flanges PN16 for vertical mounting
o Pump unit on pedestal for vertical mounting
2 Size Corresponds to delivery rate in [l/min] at 1450 min
-1
3 Shaft seal A Standard mechanical seal
B Mechanical seal of hard material
C Standard radial shaft seal
D Magnetic coupling
E Mechanical seal with quench
F High-temperature radial shaft seal
X Special design
4 Pressure stage over-
flow valve
A Pressure stage 3.0– 5.9 bar
B Pressure stage 6.0– 9.9 bar
C Pressure stage 10– 16 bar
X Special design
5 Heating A Without heating
B Electrical heating system
C Fluid heating system
X Special design
6 Version index For internal administration
Tab.2: Type code
