16 Spare parts
16.3 Repair kits
16.3.4 Repair kit overflow valve KF/KH/KV2200–2900
Notice The repair kit contains only the numbered parts and is only supplied complete.
164
914.2
914.6*
039
501
064
305
629
306
729.4
914.5
165.1
Qty. Item No. Part Qty. Item No. Part
1 039 Sleeve 1 501 Pressure spring
1 064 Supporting ring 1 629 Valve housing
1 164 Adjusting screw 1 729.4 Flat gasket
1 165.1 Screw plug 7 914.2 Socket screw
1 305 Valve body 3 914.5 Socket screw
1 306 Groove nut 4 914.6* Socket screw
* Only for Type KV: replaces 4 pieces 914.2
Tab.28: Repair kit overflow valve KF/KH/KV2200–2900
