Loading and Saving Configurations
VP-427X1 enables you to save a configuration to recall it in the future.
Saving a Configuration
To save the current configuration:
1. Configure the device as required.
2. In the Navigation pane, click Save.
The file is automatically saved in the Downloads folder (or another designated folder).
The current configuration is saved.
Loading a Configuration
To load a configuration:
1. In the navigation pane click Upload.
An Explorer window opens.
2. Select the required file and click Open.
The device is configured according to the saved preset.
Entering Standby Mode
VP-427X1 features a power saving standby mode that shuts down its outputs without having
to power off the unit.
To toggle between standby mode and normal operation:
• Click the power icon on the right-hand side of the web pages header.
When in standby mode, the icon displays a gray background:
Figure 11: VP-427X1 Standby Mode
