Defining CEC Functionality
Define whether the unit automatically sends CEC on/off commands to the display (default) or
whether it passes CEC commands from the source to the display (see Defining CEC
on page 17).
To define the CEC behavior:
1. Click Advanced on the Navigation List.
The Advanced page appears.
2. Define Output CEC Bypass from the drop-down box:
▪ Off – Automatically send CEC commands to shut down the output display after a
timeout period when no input signal is found and to power up the display when the
input returns.
▪ On – Pass CEC commands from the source to the display.
CEC functionality is defined.
Defining the TOGGLE Pin Behavior
VP-427X1 enables defining the function of the REMOTE pin on the rear panel.
To configure the TOGGLE pin (see Connecting the Remote Control Switches on page 9):
1. Click Advanced on the Navigation List.
The Advanced page appears.
2. Select the TOGGLE pin configuration from the drop-down box:
▪ Edge = (toggle on/off).
▪ Input Select.
▪ GND=Off / Hi=On
▪ GND=On / Hi=Off
▪ Hi=Off
▪ Hi=On
▪ GND=Off
▪ GND=On
TOGGLE pin button is defined.
