VP-427X1 – Operating and Controlling VP-427X1
17
Defining CEC
VP-427X1 can be configured to automatically send CEC on/off commands to the connected
display (default) or to pass CEC commands from the connected source to the connected
display.
To set the CEC (Consumer Electronic Control) functionality:
1. On the front panel press MENU. The menu appears.
2. Click Advanced and select Output CEC Bypass.
3. Select:
▪ Off – Automatically send CEC commands to shut down the output display after a
timeout period when no input signal is found and to power up the display when the
input returns.
▪ On – Pass CEC commands from the source to the display.
CEC functionality is defined.
Configuring TOGGLE Pin Behavior
VP-427X1 enables defining the function of the REMOTE pin on the rear panel.
To configure the TOGGLE pin (see Connecting the Remote Control Switches on page 9):
1. On the front panel press MENU. The menu appears.
2. Click Advanced and select Toggle Pin.
3. Select the TOGGLE pin configuration:
▪ Edge = (toggle on/off).
▪ Input Select.
▪ GND=Off / Hi=On
▪ GND=On / Hi=Off
▪ Hi=Off
Defining HDBT Range
VP-427X1 enables defining the HDBT port range.
To define HDBT extra range:
1. On the front panel press MENU. The menu appears.
2. Click Advanced and select HDBT Extra Range.
3. Select:
▪ Off – 1080p signal extends to 130m.
▪ On – extra range, 1080p signal extends to 180m.
HDBT range is defined.
