6. When the active input is VGA, in the Finetune area, click Auto Adjust to automatically
adjust the video output or use the slider controls to adjust the following:
▪ Phase
▪ Clock
▪ H-Position – horizontal position of the video on the display screen
▪ V-Position – vertical position of the video on the display screen
Configuring HDCP per Input/Output
VP-440 enables you to configure HDCP individually for each input/output.
To configure HDCP:
1. Click HDCP on the Navigation List.
The HDCP page appears.
Figure 25: The HDCP Page
2. In the On Output area, click one of the following for each of the outputs:
▪ Input – signal only sent with HDCP encryption when the input includes HDCP
encryption.
▪ Output – signal is always sent with HDCP encryption when the output supports it,
even if the input does not include encryption.
3. In the On Input area, click ON or OFF for each of the four inputs to turn on or off the
HDCP encryption for that input.
