Kramer VP-440X User Manual

Kramer Electronics Ltd.
VP-440X – Operating and Controlling VP-440X
16
Setting HDCP
VP-440X enables setting the HDCP on the input and on the output via the front panel MENU
buttons.
To set the HDCP on the inputs and output:
1. On the front panel press MENU. The menu appears.
2. Click Advanced and define the HDCP parameters according to the information in the
following table:
Menu Item
Function
HDCP On Input
Set HDCP support on HDMI 1 IN to HDMI 4 IN to ON (default) or OFF.
Note that:
1. HDCP must be enabled (ON) to support HDCP encrypted
sources.
2. Sources such as Mac computers always encrypt their outputs
when detecting that the sink supports HDCP. If the content does
not require HDCP, you can prevent these sources from
encrypting by disabling (OFF) HDCP on the input.
HDCP On Output
Select FOLLOW OUTPUT (default) or FOLLOW INPUT on HDMI
OUT.
Select FOLLOW OUTPUT (recommended) for the scaler to match its
HDCP output to the HDCP setting of the acceptor to which it is
connected.
Select FOLLOW INPUT to change its HDCP output setting according
to the HDCP of the input (recommended when the output is connected
to a splitter/switcher).
HDCP is set on the input/output.
Setting Sleep Mode
Auto Sync Off turns off the output after a period of not detecting a valid video signal on the
input(s) until a valid input is again detected or any keypad button is pressed.
VP-440X enables configuring the Auto Sync Off delay time when a connected display enters
sleep mode.
To set Auto Sync Off:
1. On the front panel press MENU. The menu appears.
2. Click Advanced and select Auto Sync Off.
3. Define Auto Sync Off according to the information in the following table:
Menu Item
Function
Off (default)
Leave outputs active always.
Slow
Disable outputs after ~ 2 minutes of no input detection.
Fast
Disable outputs after ~ 10 seconds of no input detection.
Immediate
Disable outputs immediately.
Sleep mode is defined.

Kramer VP-440X Specifications

General

Control type	Buttons
Product color	Black
EDID management	Yes
Housing material	Aluminum
Scaled resolutions	640 x 480, 800 x 600, 1024 x 768, 1280 x 1024, 1280 x 768, 1280 x 800, 1360 x 768, 1400 x 1050, 1440 x 900, 1600 x 1200, 1680 x 1050, 1920 x 1080, 1920 x 1200, 3840 x 2160
HDMI in	4
RJ-45 ports quantity	2
Number of HDMI outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
HDCP version	1.4/2.2
Supported frame rate	24, 25, 30, 50, 60 fps
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p
Supported chroma subsampling	4:4:4
Power consumption (typical)	18 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Package depth	212 mm
Package width	351 mm
Package height	72 mm
Package weight	1600 g

Weight and Dimensions

Depth	163 mm
Width	214.6 mm
Height	43.6 mm
Weight	1100 g
