VS-211XS, VS-411XS – Protocol 3000
77
Function
Description
Syntax
Parameters/Attributes
Example
NET-CONFIG?
Get a network
configuration.
Parameters
[DNS1] and
[DNS2]are optional.
For Backward
compatibility, the id
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
If the gateway
address is not
compliant to the
subnet mask used
for the host IP, the
command will return
an error. Subnet and
gateway compliancy
specified by
RFC950.
COMMAND
#NET-CONFIGnetw_id,net_ip,net_mask,gateway,[dns1],[dns2]
<CR>
FEEDBACK
~nn@NET-CONFIGnetw_id,net_ip,net_mask,gateway<CR><LF>
netw_id – 0
net_ip – Network IP
net_mask – Network mask
gateway – Network gateway
Get the device
network parameters:
#NET-CONFIG?0<C
R>
NET-DHCP
Set DHCP mode.
Only 1 is relevant
for the mode value.
To disable DHCP,
the user must
configure a static IP
address for the
device.
Connecting Ethernet
to devices with
DHCP may take
more time in some
networks.
To connect with a
randomly assigned
IP by DHCP, specify
the device DNS
name (if available)
using the NAME
command. You can
also get an assigned
IP by direct
connection to USB or
RS-232 protocol
port, if available.
For proper settings
consult your network
administrator.
For Backward
compatibility, the id
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
COMMAND
#NET-DHCPnetw_id,dhcp_state<CR>
FEEDBACK
~nn@NET-DHCPnetw_id,dhcp_state<CR><LF>
netw_id – Network ID–the device
network interface (if there are more than
one). Counting is 0 based, meaning the
control port is ‘0’, additional ports are
1,2,3….
dhcp_state –
0 – Do not use DHCP. Use the IP set
by the factory or using the net-ip
or net-config command.
1 – Try to use DHCP. If unavailable,
use the IP set by the factory or
using the net-ip or net-config
command.
Enable DHCP mode
for port 1, if available:
#NET-
DHCP1,1<CR>
NET-DHCP?
Get DHCP mode.
For Backward
compatibility, the id
parameter can be
omitted. In this case,
the Network ID, by
default, is 0, which is
the Ethernet control
port.
COMMAND
#NET-DHCP?netw_id<CR>
FEEDBACK
~nn@NET-DHCPnetw_id,dhcp_state<CR><LF>
netw_id – Network ID–the device
network interface (if there are more than
one). Counting is 0 based, meaning the
control port is ‘0’, additional ports are
1,2,3….
dhcp_state –
0 – Do not use DHCP. Use the IP set
by the factory or using the net-ip
or net-config command.
1 – Try to use DHCP. If unavailable,
use the IP set by the factory or
using the net-ip or net-config
command.
Get DHCP mode for
port 1:
#NET-DHCP?1<CR>
NET-GATE
Set gateway IP.
A network
gateway connects
the device via
another network and
maybe over the
Internet. Be careful
of security issues.
For proper settings
consult your network
administrator.
COMMAND
#NET-GATEip_address<CR>
FEEDBACK
~nn@NET-GATEip_address<CR><LF>
ip_address – Format: xxx.xxx.xxx.xxx
Set the gateway IP
address to
192.168.0.1:
#NET-
GATE192.168.000
.001<CR>
NET-GATE?
Get gateway IP.
A network
gateway connects
the device via
another network and
maybe over the
Internet. Be aware of
security problems.
COMMAND
#NET-GATE?<CR>
FEEDBACK
~nn@NET-GATEip_address<CR><LF>
ip_address – Format: xxx.xxx.xxx.xxx
Get the gateway IP
address:
#NET-GATE?<CR>
