Kramer VS-62HA

8
VS-62HA - Overview
VS-62HA – Overview
7
#
Feature
Function
11
INPUT Selector Buttons (1 to 6)
TO OUT 2
Press one of the six inputs to switch it to Output 2
12
OFF Button
Press to turn off output 2 video and audio
13
LOCK Button
Press to inactivate/activate all front panel buttons to prevent tampering
14
PATTERN Button
Press to activate the test pattern generator. When the generator is active, press one of
the input buttons to select a test pattern
15
ANALOG Button
Press to select the analog audio of output 2
16
VOL+ Button
Press to increase output 2 volume
17
VOL- Button
Press to decrease output 2 volume
18
MUTE Button
Press to toggle muting of output 2 audio
19
SWAP Button
Press to swap output 1 and output 2
