Kramer VS-62HA

72
VS-62HA - Protocol 3000 Commands
15.7 EDID Handling Commands
Command
Description
Type
Permission
CPEDID
Copy EDID data from the output to the
input EEPROM
EDID Handling
End User
GEDID
Set/get EDID data
EDID Handling
End User
LDEDID
Load EDID data
EDID Handling
End User
Command - CPEDID
Command Type - EDID Handling
Command Name
Permission
Transparency
Set:
CPEDID
End User
Public
Get:
-
-
-
Description
Syntax
Set:
Copy EDID data from the output to
the input EEPROM
#CPEDID␠ src_type, src_id, dst_type,
dest_bitmap␍
Get:
-
-
Response
~nn@CPEDID␠ src_stg, src_id, dst_type, dest_bitmap␍␊
Parameters
src_type - EDID source type (usually output) (see Section 18.16 EDID Source)
src_id - number of chosen source stage (1.. max number of inputs/outputs)
dst_type - EDID destination type (usually input) (see Section 18.16 EDID Source)
dest_bitmap - bitmap representing destination IDs. Format: XXXX…X, where X is hex digit. The binary
form of every hex digit represents corresponding destinations. Setting ‘1’ says that EDID data has to be
copied to this destination
Response Triggers
Response is sent to the com port from which the Set was received (before execution)
Notes
Destination bitmap size depends on device properties (for 64 inputs it is a 64-bit word)
Example: bitmap 0x0013 means inputs 1,2 and 5 are loaded with the new EDID
