KTM 200 DUKE 2021 - Tires; Fork; Shock Absorber; Chassis Tightening Torques

TECHNICAL DATA 22
103
License plate lamp LED
22.6 Tires
Front tire Rear tire
110/70 R 17 M/C 54S TL
MRF REVZ‑C1
150/60 R 17 M/C 66S TL
MRF REVZ‑C1
The tires specified represent one of the possible series production tires. Additional information is available in
the Service section under:
KTM.COM
22.7 Fork
Fork article number F20123401O
Fork WP Suspension
Fork length 755 mm (29.72 in)
22.8 Shock absorber
Shock absorber article number S20120801O
Shock absorber WP Suspension
Spring preload
Standard 3 clicks
Fitted length 307 mm (12.09 in)
22.9 Chassis tightening torques
Screw, chain guard EJOT PT
®
K60x30 7 Nm (5.2 lbf ft)
Remaining screws, chassis M4 4 Nm (3 lbf ft)
Remaining nuts, chassis M5 5 Nm (3.7 lbf ft)
Remaining screws, chassis M5 5 Nm (3.7 lbf ft)
Screw, chain guard M5 7 Nm (5.2 lbf ft)
Loctite
®
243™
Screw, compensating tank cap
lock, rear brake
M5 9 Nm (6.6 lbf ft)
Screw, fuel tank cover M5 4 Nm (3 lbf ft)
Screw, outer clutch cable guide M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, side stand sensor M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Screw, tail light M5 5 Nm (3.7 lbf ft)
Nut, foot brake lever adjustment M6 9 Nm (6.6 lbf ft)
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft)
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
Screw, ABS hose clamp M6 7 Nm (5.2 lbf ft)
Screw, ABS module M6 10 Nm (7.4 lbf ft)
Screw, ABS module retaining
bracket on frame
M6 7 Nm (5.2 lbf ft)
Screw, air filter box M6 6 Nm (4.4 lbf ft)
