COMBINATION INSTRUMENT 7
21
7.1 Combination instrument
A00968-10
The combination instrument is attached in front of the handlebar.
1
Indicator lamps ( p. 23)
2
Display ( p. 25)
3
Function buttons ( p. 26)
7.2 Activation and test
A00969-10
Activation
The combination instrument is activated when the ignition is
switched on.
Info
The brightness of the displays is controlled by an ambient
light sensor in the combination instrument.
Test
When the ignition is switched on, all indicator lamps light up
briefly except for the turn signal indicator lamp and immobilizer
indicator lamp.
The segments in the rpm gauge and the gear indicator light up and
switch off in sequence.
The speedometer counts from 0 to 199 and back.
The remaining display segments of the display light up briefly.
The READY TO >> RACE logo appears on the display.
The previously selected ABS mode is then displayed for 4 sec-
onds.
The display then changes to the last selected mode.
Info
The malfunction indicator lamp always lights up as long as
the engine is not running. If the engine is running and the
malfunction indicator lamp lights up, stop (taking care not
to endanger yourself or other road users in the process) and
contact an authorized KTM workshop.
