TECHNICAL DATA 22
105
Screw, engine bearer M8 22 Nm (16.2 lbf ft)
Screw, foot brake lever M8 16 Nm (11.8 lbf ft)
Loctite
®
243™
Screw, fork stub M8 15 Nm (11.1 lbf ft)
Screw, front brake disc M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, front seat fixing M8 25 Nm (18.4 lbf ft)
Screw, front wheel spindle M8 25 Nm (18.4 lbf ft)
Screw, fuel tank M8 20 Nm (14.8 lbf ft)
Screw, grab handle M8 22 Nm (16.2 lbf ft)
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, horn M8 12 Nm (8.9 lbf ft)
Screw, main silencer M8 23 Nm (17 lbf ft)
Screw, passenger footrest unit M8 22 Nm (16.2 lbf ft)
Loctite
®
243™
Screw, rear brake disc M8 21 Nm (15.5 lbf ft)
Loctite
®
243™
Screw, rear seat fixing M8 18 Nm (13.3 lbf ft)
Screw, seat support plate M8 18 Nm (13.3 lbf ft)
Screw, subframe M8 25 Nm (18.4 lbf ft)
Loctite
®
620™
Screw, top triple clamp M8 15 Nm (11.1 lbf ft)
Screw, front brake caliper M8x1 30 Nm (22.1 lbf ft)
Loctite
®
243™
Banjo bolt, brake line M10 24 Nm (17.7 lbf ft)
Fitting side stand M10 35 Nm (25.8 lbf ft)
Loctite
®
243™
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft)
Remaining screws, chassis M10 45 Nm (33.2 lbf ft)
Screw, engine bearer M10 49 Nm (36.1 lbf ft)
Loctite
®
243™
Fitting, handlebar support M10x1.25 21 Nm (15.5 lbf ft)
Fitting, shock absorber, bottom M10x1.25 51 Nm (37.6 lbf ft)
Loctite
®
243™
Nut, left rear mirror M10x1.25 16 Nm (11.8 lbf ft)
Nut, right rear mirror M10LHx1.25 16 Nm (11.8 lbf ft)
Nut, side stand bracket M10x1.25 35 Nm (25.8 lbf ft)
Screw, combination instrument
bracket
M10x1.25 21 Nm (15.5 lbf ft)
Screw, front footrest bracket M10x1.25 44 Nm (32.5 lbf ft)
Loctite
®
243™
Screw, front footrest bracket /
engine bearer
M10x1.25 49 Nm (36.1 lbf ft)
Screw, top shock absorber M10x1.25 51 Nm (37.6 lbf ft)
Loctite
®
243™
Stud, rear sprocket M10x1.25 50 Nm (36.9 lbf ft)
Nut, rear wheel spindle M14x1.5 98 Nm (72.3 lbf ft)
Nut, swingarm pivot M14x1.5 98 Nm (72.3 lbf ft)
