15 ELECTRICAL SYSTEM
76
S04216-10
To change the fuse of the ABS hydraulic unit:
–
Take off the protection cap and remove fuse
1
.
Info
A faulty fuse has a burned-out fuse wire
A
.
Warning
Fire hazard Incorrect fuses overload the electrical
system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
– Insert the spare fuse with the correct rating.
Fuse (75011088010) ( p. 102)
Tip
Insert spare fuse
2
in the fuse box so that it is
available if needed.
– Mount the protection cap.
S04216-11
To change the fuse of the ABS return pump:
–
Take off the protection cap and remove fuse
3
.
Warning
Fire hazard Incorrect fuses overload the electrical
system.
– Only use fuses with the required ampere value.
– Do not bypass or repair fuses.
– Insert the spare fuse with the correct rating.
Fuse (75011088015) ( p. 102)
Tip
Insert spare fuse
4
in the fuse box so that it is
available if needed.
– Mount the protection cap.
Finishing work
– Mount the passenger seat. ( p. 52)
