18 SERVICE WORK ON THE ENGINE 160
Info
Drain the engine oil while the engine is at operating temperature.
H01066-10
Main work
– Rest the motorcycle on its side stand on a horizontal surface.
– Place a suitable container under the engine.
–
Remove oil filler plug
with the O-ring from the clutch cover.
K00370-10
–
Remove oil drain plug
with the magnet and seal ring.
– Completely drain the engine oil.
– Thoroughly clean the oil drain plug with magnet.
– Mount and tighten the oil drain plug with the magnet and a new seal ring.
Guideline
Oil drain plug with magnet M12x1.5 20 Nm
(14.8 lbf ft)
