18 SERVICE WORK ON THE ENGINE 161
K00371-10
–
Remove screws
. Remove oil filter cover
with the O-ring.
–
Pull oil filter
out of the oil filter housing.
Circlip pliers reverse (51012011000)
– Thoroughly clean the parts and sealing surface.
K00417-10
–
Remove screws
. Remove oil filter cover
with the O-ring.
–
Pull oil filter
out of the oil filter housing.
Circlip pliers reverse (51012011000)
– Completely drain the engine oil.
– Thoroughly clean the parts and sealing surface.
K00372-10
– Insert the new oil filter.
–
Oil the O-rings of the oil filter covers. Position oil filter cover
and
.
– Mount and tighten the screws.
Guideline
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)
