22 TECHNICAL DATA 176

Remaining screws, engine M5 6 Nm (4.4 lbf ft) –

Screw, clutch spring M5x25 6 Nm (4.4 lbf ft) –

Screw, cover plate for oil return line M5 6 Nm (4.4 lbf ft) –

Screw, gear position sensor M5x14 5 Nm (3.7 lbf ft) Loctite

243™

Screw, oil filter cover M5 6 Nm (4.4 lbf ft) –

Screw, oil pump cover M5 6 Nm (4.4 lbf ft) Loctite

243™

Screw, oil pump cover, top M5 6 Nm (4.4 lbf ft) Loctite

243™

Chain securing guide M6 5 Nm (3.7 lbf ft) –

Remaining screws, engine M6 10 Nm (7.4 lbf ft) –

Screw in alternator cover M6 10 Nm (7.4 lbf ft) –

Screw, alternator cover M6x30 10 Nm (7.4 lbf ft) –

Screw, alternator cover (chain shaft

through-hole)

M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, autodecompression M6 3… 4 Nm (2.2… 3 lbf ft) Loctite

243™

Screw, axial lock of camshaft M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, camshaft bearing support M6x80 10 Nm (7.4 lbf ft) –

Screw, camshaft bearing support M6x90 10 Nm (7.4 lbf ft) –

Screw, chain shaft M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, clutch slave cylinder M6x20 10 Nm (7.4 lbf ft) Loctite

243™

Screw, clutch slave cylinder M6x35 10 Nm (7.4 lbf ft) –

Screw, cylinder M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, cylinder head M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, engine case M6 10 Nm (7.4 lbf ft) –

Screw, ignition coil M6 10 Nm (7.4 lbf ft) –
