22 TECHNICAL DATA 177
Screw, ignition pulse generator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, locking lever M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, oil pump cover, bottom M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, resonator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, stator M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, thermostat housing M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, timing chain guide rail M6x30 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, timing chain tensioning rail M6x30 10 Nm (7.4 lbf ft) Loctite
®
243™
Screw, valve cover M6 10 Nm (7.4 lbf ft) –
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Screw, water pump wheel M6 10 Nm (7.4 lbf ft) Loctite
®
243™
Screws, SAS cover M6x12 10 Nm (7.4 lbf ft) Loctite
®
243™
Intake channel vacuum connection M6x0.75 2.5 Nm (1.84 lbf ft) Loctite
®
243™
Oil jet, piston cooling M6x0.75 4 Nm (3 lbf ft) Loctite
®
243™
Screw plug, crankshaft clamp M8 15 Nm (11.1 lbf ft) –
Screw, rocker arm shaft M8x40 15 Nm (11.1 lbf ft) –
Screw, rocker arm shaft M8x55 15 Nm (11.1 lbf ft) –
Stud, exhaust flange M8 10 Nm (7.4 lbf ft) Loctite
®
243™
