23 TECHNICAL DATA 119

Plug, vacuum connection M6 2.5 Nm (1.84 lbf ft) Loctite

243™

Screw plug EVAP M6 5 Nm (3.7 lbf ft) Loctite

243™

Screw, alternator cover M6x25 10 Nm (7.4 lbf ft) –

Screw, camshaft bearing support M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, clutch cover M6x25 10 Nm (7.4 lbf ft) –

Screw, cylinder head M6 10 Nm (7.4 lbf ft) –

Screw, engine case M6x40 10 Nm (7.4 lbf ft) –

Screw, engine case M6x60 10 Nm (7.4 lbf ft) –

Screw, engine case M6x75 10 Nm (7.4 lbf ft) –

Screw, engine case M6x80 10 Nm (7.4 lbf ft) –

Screw, engine case M6x85 10 Nm (7.4 lbf ft) –

Screw, exhaust flange M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, idler M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, kick starter spring hanger M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, kick starter stop M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, oil pump cover M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift drum locating M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, shift lever M6 14 Nm (10.3 lbf ft) Loctite

243™

Screw, starter motor M6 10 Nm (7.4 lbf ft) –

Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, timing chain tensioner M6 10 Nm (7.4 lbf ft) –

Screw, timing chain tensioning rail M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, torque governor M6 10 Nm (7.4 lbf ft) Loctite

243™

Screw, valve cover M6 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x25 10 Nm (7.4 lbf ft) –

Screw, water pump cover M6x55 10 Nm (7.4 lbf ft) –

Oil jet for balancer shaft lubrication M6x0.75 4 Nm (3 lbf ft) –

Oil nozzle for conrod bearing lubrica-

tion

M6x0.75 4 Nm (3 lbf ft) –

Plug, oil channel M7 9 Nm (6.6 lbf ft) Loctite

243™

Screw, rocker arm bearing M7x1 15 Nm (11.1 lbf ft) –

Plug, crankshaft location M8 10 Nm (7.4 lbf ft) –

Screw, kick starter M8 25 Nm (18.4 lbf ft) Loctite

2701™

Plug, timing chain tensioner M8x1 8 Nm (5.9 lbf ft) –

Plug, oil drilling M10 15 Nm (11.1 lbf ft) Loctite

243™

Screw, engine sprocket M10 60 Nm (44.3 lbf ft) Loctite

2701™

Screw, cylinder head M10x1.25 Tightening sequence:

Tighten diagonally, begin-

ning with the rear screw on

the timing chain shaft.

Step 1

10 Nm (7.4 lbf ft)

Step 2

30 Nm (22.1 lbf ft)

Step 3

50 Nm (36.9 lbf ft)

Lubricated with engine oil

Nut, rotor M12x1 60 Nm (44.3 lbf ft) –

Spark plug M12x1.25 15… 20 Nm (11.1…

14.8 lbf ft)

–

Engine coolant temperature sensor M12x1.5 12 Nm (8.9 lbf ft) –

Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Oil pressure control valve plug M12x1.5 20 Nm (14.8 lbf ft) –

Plug, rocker arm M14x1.25 20 Nm (14.8 lbf ft) –

Nut, inner clutch hub M18x1.5 80 Nm (59 lbf ft) –
