12 SERVICE WORK ON THE CHASSIS 70
M01023-10
(EXC Six Days)
– Disconnect the connector of the horn.
–
Remove screws

with the collar bushings and horn.
K00146-10
(XC‑W)
–
Remove screws

with the collar bushings.
K00104-10
–
Remove screw

with the rubber bushing.
K00105-10
(EXC EU/AU, XC‑W)
– Pull both spoilers off of the sides of the radiator bracket and lift off the fuel
tank.
M01025-01
(EXC Six Days)
– Pull both spoilers off of the sides of the radiator bracket and lift off the fuel
tank.
12.34 Installing the fuel tank
Danger
Fire hazard Fuel is highly flammable.
– Never refuel the vehicle near open flames or burning cigarettes, and always switch off the engine first. Be careful that no
fuel is spilt, especially on hot vehicle components. Clean up spilt fuel immediately.
– The fuel in the fuel tank expands when warm and may emerge if overfilled. Follow the instructions on refueling.
