6 CONTROLS 18
6.18 Shift lever
401950-10
The shift lever
is fitted on the left side of the engine.
401950-11
The gear positions can be seen in the photograph.
The neutral or idle position is between the first and second gears.
6.19 Kick starter
401954-10
The kick starter
is fitted on the right of the engine.
The engine can be started with either the kick starter or the electric starter.
The upper part of the kick starter can be swung out.
Info
Before riding, swing the top part of the kick starter inwards towards the engine.
6.20 Foot brake lever
401956-10
The foot brake lever
is attached in front of the right footrest.
The foot brake lever is used to activate the rear brake.
6.21 Side stand
401943-10
The side stand
is attached to the left side of the vehicle.
