Control box
16
Quantron S
Assembly and fitting
- Make sure to avoid friction or crushing areas when
installing the power cable.
Control box power supply is from the tractor 3-pin
auxiliary power supply.
3. Control box connection
Carry out following tasks in the given order:
- Fit the control box in a position where the driver can
see it in the tractor cab.
- Connect the machines' 39-pin cable.
- Connect the control box to the power supply (See
chapter Electrical power supply).
On tractor's fitted as standard with a 3-pin
plug, check the wire polarity to avoid causing
damage to the control box
The Quantron S control box is factory set for
the machine supplied.
Only connect the supplied control box to the
concerned machine.
