Control box
12
Quantron S
General description
3. Description of control elements
0
1 : Distribution stop/start 2 : Delete / rollback
3 : Switch between the display of the application
rate and the display of the hydraulic valve bank
functions
4 : Rollback to the tramlining counter
position
5 : Access to the general menu 6 : ESC key
7 : Navigating keys with confirmation key 8 : F1 to F4 function keys
9 : Daily counters 10 : Display
11 : On/Off switch 0
When used in MANUAL mode, key Start/Stop is
not operational.
