Control box
46
Quantron S
Functioning during work
2. Hydraulic valve bank
Functions available For Speedliner
3000/4000/6000.
- Press on the button hy: The screen displays the
hydraulic selector functions.
Functions not activated:
• (1): The side markers can be controlled by the
tractors' hydraulic outlet.
• (2): The preparation tools can be lowered or raised
using the tractors' hydraulic valve
Functions activated (Black background):
• Roller pressure (1)
• Hydraulic roll folding (2)
