Functioning during work
Control box
Quantron S
45
Stopping tramlining temporarily
The button "Pause" avoids that the counting is continued
whilst going around an obstacle.
Condition: the working screen must be displayed.
- Press key F1 (1) (REST).
If the seed drill is fitted with a circuit selector:
- Press on the button hy: The screen displays the
hydraulic selector functions.
- Press on function F3 (1) : Confirm the marker lift
function.
- After goind round the obstacle, press key F3
Lower marker and coulter bar.
- Press key F1 (2) (REST).
The tramlining counting will continue. Quantity and
distance counting will carry on.
