Control box
62
Quantron S
Trouble shooting guide
The pre-emergence marker
solenoid valve does not
function.
Bad connection
- Check the power connection
- Connect wire marked L of wiring
harness Y to the solenoid valve.
- The wire marked R of wiring harness Y
must be connected to a second
solenoid valve for special rhythms.
The tramlining rhythm is not
counted.
The PAUSE key has been
activated.
- Press key F1 (REST).
The marker manoeuvre does not
affect the tramlining counting.
- The pulses for tramlining are sent by
the wrong sensors.
- In the "tramlining" sub-menu of the
"Hopper configuration" menu, activate
counter on SPR (markers).
Faulty side marker sensor
- Test the sensors using the diagnosis
menu.
Problem Cause Remedy
