Maintenance work
26
User's guide
5.4. Dismantling/assembling the shelf runners
12 rack levels are available in the side racks. Rack levels are counted from the top to the bottom from 1 to
12. Rack level 1 is the lowest rack level.
Dismantling
□ Open the door as far as it will go.
□ Take the accessories out of the appliance.
□ Completely loosen the nut at the front of the fastening element
(A), pull the supports forward (B) and remove them.
□ Removing the side racks.
□ Insert the rear notch into the rear fastening nut.
□ Fix the front fastening nut (C) in the front notch of the support.
□ Secure the support with the nut (D) and turn until it is fully ad-
justed (E).
5.5. Dismantling the rear wall
First of all remove the side runner to remove the rear wall, following the instructions in the
previous section.
□ Remove the lower four screws (1) and then the top screw (B).
To assemble rear wall, carry out the steps in the reverse order.
ATTENTION!
NEVER start a process if the rear wall is missing!
