Maintenance Port Parser Commands
54-0161
159
Report RF Tracking Parameters
Function: reports all RF tracking parameters for primary &
secondary satellites*
Command: @SATCONFIG
Response: F,x,fffff,S,C,ID,P,B,D <cr>
Where: x = Satellite (A = Primary, B = Secondary)
fffff = frequency in MHz (00000 and 10700 to
12700)
S = symbol rate in Mbit/Sec (1000 to 29999)
C = FEC code rate (valid rates = 12, 23, 34, 56,
67, 78)
ID = satellite network ID in hexidecimal format
(valid range = 0x0000 to 0xffff hex)
P = LNB polarization (V = vertical, H = horizontal,
R = right, L = left)
B = the LNB down conversion frequency (L = low,
H = high, G = Latin America, U = USA)
D = decoding type (0 = test, 1 = DSS-A, 2 = DSS-B,
3 = DVB)
* This command returns all eight combinations of the Satellite/Freq/Sym/
FEC/ID/POL/Band/Decode currently stored in RAM.
