KVH Industries TracVision G6 Technical Manual

Multiple Multiswitch Installation
If you need to connect more than four IRDs to the TracVision
antenna, you may carry out a multiple multiswitch installation,
as shown in Figure 2-18.
54-0161
28
TracVision G6 Technical Manual
Multiswitch
DC In RHCP
+13v
VHF/UHF LHCP
+18v
Out 1 Out 2 Out 3 Out 4
DC Power
Multiswitch
DC In RHCP
+13v
VHF/UHF LHCP
+18v
Out 1 Out 2 Out 3 Out 4
DC Power
IRD #5 IRD #6 IRD #8IRD #7
RF Splitters/
Power Dividers
IRD #2 IRD #3
IRD #4
RF1 RF2
IRD #1
TracVision Antenna Baseplate
Figure 2-18
Multiple Multiswitch Installation
(North American and Latin
American systems only)
