Programming User-defined Satellites
The TracVision G6 satellite library has the capacity for two user-
defined satellites in case you want to track a satellite that is not in
the KVH predefined list. User-defined satellites can only be
configured via the ADCU’s maintenance port. To configure a user
satellite, information about the satellite must be provided,
including:
• Satellite name
• Satellite position (longitude)
•Transponder information for each of the following
polarizations/frequencies:
- vertical high
- vertical low
- horizontal high
- horizontal low
or
- right
- left
•Transponder information includes:
-frequency
- symbol rate
- FEC code, and
- network ID (in hexidecimal format)
This information can be obtained from your satellite service
provider or from a number of sites on the Internet, such as
www.satcodx.com.
Installation
54-0161
49
How to tell the difference between
High and Low bands:
High: 11.700 - 12.750 GHz
Low: 10.700 - 11.700 GHz
For your reference, the satellite
configuration information for the
predefined satellites is available on
our web site at www.kvh.com/
footprint/index.html.
