Kyocera KM-1820

Maintenance
Description
item No.
3JG
1-3-14
U632 Setting communication control 3
Description
Makes settings for fax transmission regarding the communication.
Start
1. Press the enter key. The screen for selecting an item is displayed.
2. Select the item to be set using the up/down cursor keys.
3. Press the enter key. The screen for the selected item appears.
Display Description
1:DIS 4BYTE Sets the DIS signal to 4 bytes.
2:SHORT PROTO TX Sets the short protocol transmission.
3:SHORT PROTO RX Sets the reception of short protocol transmission.
4:NUM OF CNG (F/T) Sets the CNG detection times in the fax/telephone auto select
mode.
Setting the DIS signal to 4 bytes
Sets if bit 33 and later bits of the DIS/DTC signal are sent.
1. Change the setting using the up/down cursor keys.
Display Description
1: ON Bit 33 and later bits of the DIS/DTC signal are not sent.
2: OFF Bit 33 and later bits of the DIS/DTC signal are sent.
2. Press the enter key. The value is set.
3. To return to the screen for selecting an item, press the back key.
Setting the short protocol transmission
Sets if short protocol transmission is performed.
1. Change the setting using the up/down cursor keys.
Display Description
1: ON Short protocol transmission is performed.
2: OFF Short protocol transmission is not performed.
2. Press the enter key. The value is set.
3. To return to the screen for selecting an item, press the back key.
Setting the reception of a short protocol transmission
Selects whether to receive or ignore transmission using short protocol.
If a short protocol transmission is received when an auto switching device is attached to the machine,
communication problems, including auto switching inability, sometimes occur. Change the setting to ignore
short protocol transmission to prevent such problems.
1. Change the setting using the up/down cursor keys.
Display Description
1: ON Receives short protocol transmission.
2: OFF Ignores short protocol transmission.
2. Press the enter key. The value is set.
3. To return to the screen for selecting an item, press the back key.
Setting the CNG detection times in the fax/telephone auto select mode
Sets the CNG detection times in the fax/telephone auto select mode.
1. Change the setting using the up/down cursor keys.
Display Description
1: 1 TIME Detects CNG once.
2: 2 TIMES Detects CNG twice.
2. Press the enter key. The value is set.
3. To return to the screen for selecting an item, press the back key.
Completion
Press the back key at the screen for selecting an item. The screen for selecting a maintenance item No. is
displayed.
