Quickstart
How do I run a diagnostic on the sash position switches?
1. Press the Menu button.
2. Press the ▼ button until the Services option is highlighted (it will
turn yellow).
3. Press OK/Mute to enter the Services menu screen.
4. Press the ▼ button until the Diagnostic Diagnostic option is
highlighted (it will turn white).
5. Press OK/Mute to enter the Diagnostic submenu.
6. Press the ▼ button until the Diagnostic Sash sensors option is
highlighted (it will turn white). Press OK/Mute .
7. Lower the sash, and note the status line – it should properly
report the sash as open too high, or open, or closed when the
sash is in the corresponding position.* Press OK/Mute to exit
the diagnostic.
*Early production models of Type A Logic+ units may display a sash height alarm screen
when the sash is raised above its operating position. This is normal.
MAIN MENU
1. MyLogic
TM
2. Settings
3. Service
or to choose,
OK to select, MENU to escape
or to choose,
OK to select, MENU to return
Current Settings
Restore Default
Calibration
Configuration
 Diagnostics

Service
or to choose,
OK to select, MENU to escape
Sash sensors 
Keypad -Relays
Canopy Alarm
Airflow Sensor

Diagnostics
OK to return
Lower the sash from full open
to closed
Note the sash status below:
Sash Status:
The sash is open
The sash is open too high
The sash is closed
Diagnostics
