Air Compressor
The Echo Liquid Handler requires a compressed air source that provides clean, filtered, oil-free, dry air at 552 kPa (80 PSI) minimum
and 1034 kPa (150 PSI) maximum. The Junair OF302-4B oil-less compressor can be purchased from Labcyte (Part #001-12164).
Note: The Junair OF302-4B compressor is only 115VAC/60Hz and is only suitable for North America.
The user must also provide a fitting between the compressed air supply and the Echo Liquid Handler. Labcyte provides the
compressed air line and fitting with the Echo Liquid Handler, but the customer must provide a source compatible with 170 in
ID/.250 in OD tubing.
The table below lists the specifications for the Junair OF302-4B compressor:
Voltage V 100 100 120 200 200 230 230 3x400 3x440
Frequency Hz 50 60 60 50 60 50 60 50 60
Motor
HP 0.60 0.60 0.60 0.60 0.60 0.60 0.60 0.60 0.60
kW 0.44 0.44 0.44 0.44 0.44 0.44 0.44 0.44 0.44
Displacement
I/min 108 138 138 108 138 108 138 108 138
CFM 3.81 4.87 4.87 3.81 4.87 3.81 4.87 3.81 4.87
FAD @ 8 bar
l/min 38 44 44 38 44 38 44 38 44
CFM 1.34 1.55 1.55 1.34 1.55 1.34 1.55 1.34 1.55
Maximum
pressure
bar 8 8 8 8 8 8 8 8 8
psi 120 120 120 120 120 120 120 120 120
Maximum current A 7.5 8.7 6.6 4.1 4.6 3.4 4.1 1.4 1.4
Tank size
litres 4 4 4 4 4 4 4 4 4
gallon 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1 1.1
Weight
kg 22 22 22 22 22 22 22 22 22
lbs 49 49 49 49 49 49 49 49 49
Noise level
dB
(A)/lm
65 66 66 65 66 65 66 65 66
Thermal
protection
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Duty cycle 100% 100% 100% 100% 100% 100% 100% 100% 100% 100%
