Labcyte Echo 525 - Vacuum Pump

Vacuum Pump
The Echo Liquid Handler requires a vacuum source. This requirement can be met through a house vacuum or a vacuum pump.
The vacuum source should have the following specifications:
l House supply: Minimum 200 Torr (266 mbar, 22 in Hg Vac) minimum pumping speed 8.0 m3/hr
l Standalone vacuum with surge tank (10 L): 100 Torr (133 mbar, 26 in Hg Vac), minimum pumping speed 2.0 m3/hr
The vacuum returns the coupling fluid to the supply bottle and dries source plates before they are unloaded. Customers must
provide a fitting that connects the vacuum source and the Echo Liquid Handler vacuum line. The supplied vacuum line is
HercoBraid, 9.5 mm (3/8 in) ID, 9.5 mm (5/8 in) OD (RyanHerco P/N 0512-072).
A standalone Vacuubrand MZ 2S-NT vacuum system can be purchased from Labcyte (Part #001-8104). This vacuum is a dual
voltage/cycle compatible system.
The table below lists the specifications for the Vacuubrand MZ 2S-NT vacuum system:
Permissible ambient temperature storage/operation
14 to 140/50 - 104 F°
-10 to +60/ +10 - +40 C°
Permissible relative atmospheric moisture during operation (no
condensation)
30 to 85%
No-load speed 50/60 hZ 1500/1800 rpm
Device fuse Slow blow fuse 6.3 A
Maximum pumping speed 50/60 Hz
1/3/1.4 cfm
2.2/2.4 m3/h
Ultimate vacuum (absolute)
5.2 Torr
7 mbar
Maximum permissible outlet pressure (absolute)
29 psi
2 bar
Maximum permissible different between inlet and outlet
29 psi
2 bar
Rated motor power
0.24 hp
0.18 kW
Maximum permissible range of supply voltage (+10%)
100-115 V ~50/60 Hz
120 V ~ 60 Hz
230 V ~50/60 Hz
Dual voltage motor
100-115 V ~50/60 Hz
120 V ~ 60 Hz
200- 230 V ~50/60 Hz
Maximum rated current at:
100-115 V ~50/60 Hz, 120 V ~ 60 Hz
200- 230 V ~50/60 Hz, 230 V ~50/60 Hz
3 A
1.8 A
Inlet
Hose nozzle for tubing I.D. 3/8 in
Hose nozzle DN 10 mm
Outlet Silencer / G1/4 in
Dimensions L X W X H (approximate)
9.6 X 9.4 X 7.8 in
243 X 239 X 198 mm
Weight (approximate)
24.2 lbs
11 kg
