6. Connect the chiller. Attach the plastic tubing between the chiller and the Echo Liquid Handler.
Figure 40: Tubing connections on the chiller
Caution: Do not run the pump until the chiller tubing is connected. Running the pump without the chiller tubing
may damage other system components.
