17
G
H
I
L
Insert the sheath using the cable guides until reaching the electric
lock.
Cut o the excess sheath.
Insert the steel cable into the release handle and into the sheath
until reaching the electric lock.
Fit the sheath end on the tip of the sheath which has been cut.
Position the compression spring and insert the metal cable inside
the special release anchor, then lock it with the screw clamp.
Adjust cable tightening so as to give the spring a light pre-load.
