Operating the AUTOMIZER
TM
HELPING-HAND 91
Figure 4-6
Floor riser in vertical position (left), in horizontal position (right)
2. If you need extra height, hold the riser with one hand before pulling it down and, with the other
hand, extend the legs.
Figure 4-7
Floor riser legs in collapsed position (left) and in extended position (right)
To put the floor riser back in its vertical position, simply reverse the procedure.
Latch
Legs
