32 Safety
Multiplexed Indicator Tops
NOTE: This illustration and the preceding one were taken from the PDF file no 159535.
NOTE: 1- All symbols to be negative lens.
2- Electronic file for the symbols available on request from Labrie Enviroquip Group only.
Safety Features
Back Up Alarm
The back up alarm sounds when the truck is in reverse or when the tailgate is open.
Body Safety Prop
Safety props ensure that heavy body parts will not move inadvertently.
Setting the Body Safety Prop
The body safety prop ensures that an empty body will not lower when you are working underneath it.
Figure 2-2
Body safety prop
Danger!
Always set the body safety prop when performing maintenance underneath a raised
body. Failure to do so may result in severe injury, or even death.
