72 Controls and Indicators
Press the switch again to turn OFF the rubrail lights (switch turns blue).
Hopper Work Light Switch
This switch (see Figure 3-19) turns ON/OFF the hopper work light.
Press the switch once to turn ON the hopper work light (switch turns green).
Press the switch again to turn OFF the hopper work light (switch turns blue).
Strobe Light Switch
This switch (see Figure 3-19) turns ON/OFF the strobe lights and the amber flashing lights.
Press the switch once to turn ON the strobe lights and the amber flashing lights (switch turns
green).
Press the switch again to turn OFF the strobe lights and the amber flashing lights (switch turns
blue).
Crusher Panel Down Switch (optional)
Press and keep down this switch (see Figure 3-18) to lower the crusher panel (see Figure 3-21) to the
desired position.
The crusher panel is an option that may be installed on an A
UTOMIZER
TM
HELPING-HAND vehicle. If
your unit is equipped with this option, we suggest you to use it only for bulky items. In many cases,
unnecessary use will slow down the operation. Bulky items can be maintained in place with the
crusher panel while the packer crushes them.
The crusher panel can be lowered upon the refuse to prevent it from popping up in front of the
packing ram, thus increasing the compaction effect during the load breaking sequence.
To help during the unloading process, a good amount of garbage should be left in front of the packer
and under the lowered crusher panel as you finish your collection route. Once the body is raised at
landfill, you can activate the packing ram to help clear whatever could be jammed in the hopper. This
procedure can also be done without the crusher panel.
Crusher Panel Up Switch (optional)
Press and keep down this switch (see Figure 3-18) to raise the crusher panel to the desired position.
Figure 3-21
Crusher panel
