Operating the AUTOMIZER
TM
HELPING-HAND 107
Figure 4-19
Arm proportional valve
3. Contact your Service Center and refer to the Troubleshooting section of the Maintenance
Manual.
Figure 4-20
4-section proportional valve
Danger!
Never drive this vehicle if the automated arm is not retracted to its home position. The
vehicle would be too high and/or too wide to be driven safely. Failure to completely
retract the arm will result in unit and/or property damage, personal injury or death.
Warning red lights on the dashboard start flashing as soon as the arm begins to extend.
Crusher Panel Down
(if installed)
Gripper Close
Arm Down
Arm Extend Arm Retract
Arm Up
Gripper Open
Crusher Panel Up
(if installed)
