3 Specifications
3.1 Electrical characteristics
Parameter Value Unit Notes
Power supply voltage Vin 11 ÷ 16 V
Power consumption (typ) 0.5 W
@12V power supply, stand-by state without faults,
actuator stopped at the selected position, without
dimming
load(motor) current (max) 9 A
Higner current activates overcurrent protection
rated motor current 4.6 A
Linak LA12 type
the dimming voltage range at the
DIMBOX accessory input
10 ÷ 16 V
PWM frequency 80 ÷ 200 Hz
Position sensor resistance 8 ÷ 12 k
Ω
Resistive sensor type
NOTE The above specifications apply to the control unit or Linak LA12 actuator
3.2 Mechanical specifications
Parameter Value Unit Notes
weight of control unit FLAPS V6
HBR
144 g
weight of Linak LA12 actuator
with 1m cable
833 g
DIMBOX accessory weight TBD g
dimensions of control unit FLAPS
V6 HBR
60 x 60 x 65 mm
dimensions of actuator Linak
LA12
266 x 85 x 50 mm
Včetně upevňovacích ok, zatažená pístnice
Dimensions of DIMBOX
accessory
42 x 12 x 16 mm
11/33
