5.4 Device setup mode
This mode is used for service setting of device functions and parameters. The device
allows you to set the following parameters and functions:
• Functionality of the LBUS pin (landing gear control output / dimmer input)
The following sequence of actions is required to enter the mode:
1) device in off state (power off)
2) Press and hold both SET buttons
3) turn on the power to the device
4) wait a few seconds for the initialization sequence to complete and then all the LEDs
turn orange or red
5) Release the SET buttons
After entering Device setup mode, the controls and indicators have the following
functions:
• rotary switch = selection of the function / parameter to be edited given by the
position of the switch lever
• SET buttons = increase or decrease the set parameter setting (parametric option)
• LEDs = numeric indication of the set value (parametric option) of the parameter
selection (in binary code, where orange is 0 and red is 1)
Overview table of possible settings:
Function / Parameter Name Parametric
Option
Function/Value
LBUS pin functionality
(switch position 0)
0* Landing gear control output
1 Input for dimming indicator elements
2
RESERVE, for future use
3*
RESERVE, for future use
* factory preset value
** cannot be selected with the rotary switch for the HBR 3P variant
