2.8 Description of the control panel
2.8.1 Control panel HBR (4 control positions)
8/33
rotary switch
lever
(points to the set
position)
position 0 with indication
LED
position 1 with indication
LED
position 2 with indication
LED
position 3 with indication
LED
SET button (UP)
SET button (DOWN)
