Using a Printer Server
62
3
N Press the {Esc} key, and then click
[Yes] on the confirmation message.
O Press the {Esc} key to return to
[Print Server Configuration Menu].
P Assign print queues to the created
printer.
Q From [Print Server Configuration Menu],
select [Queues Serviced By Printer].
R Select the printer created.
S Press the {Insert} key to select a
queue serviced by the printer.
You can select several queues.
T Follow the instructions on the
screen to make other necessary
settings.
Following these steps, check that
the queues are assigned.
U Press the {Esc} key until "Exit?"
appears, and then select [Yes] to
exit PCONSOLE.
V Start the print server by entering
the following from the console of
the NetWare server.
If the print server is in operation,
quit and restart it.
❖ To quit
CAREE: unload pserver
❖ To start
CAREE: load pserver
print
_server_name
Note
❒ If the printer works as config-
ured, the message "Waiting for
job" appears.
Setting Up as a Remote Printer
(NetWare 4.x, 5 / 5.1, 6 / 6.5)
Follow the procedure below to use
the printer as a remote printer under
NetWare 4.x, 5 / 5.1 and 6 / 6.5.
If TCP/IP and IP address is set, con-
figure using Web Image Monitor.
If IPX is set, configure using NIB Set-
up Tool.
Important
❒ To use the printer as a remote print-
er under NetWare 4.x, 5 / 5.1, 6 / 6.5,
set it to NDS mode.
❒ Do not use the printer as a remote
printer when Pure IP is used.
Setting up using NIB Setup Tool (TCP/IP)
A Log on to the file server as an ad-
ministrator or administrator
equivalent.
B Start NIB Setup Tool from the
[Start] menu.
C Click [Property Sheet], and then
click [OK].
D Select the printer you want to con-
figure, and then click [Finish ].
A dialog box prompting you to per-
form the remaining configuration
tasks in the Web browser appears.
Click [OK], and then wait until Web
Image Monitor starts automatically.
E A dialog box for entering the [User
Name] and [Password] appears.
Enter the user name and pass-
word, and then click [OK].
Note
❒ For details about the password,
consult your network adminis-
trator.
